Dial Torque Wrenches are designed for the automotive, nuclear and industrial markets in addition to military installations throughout the world. This series features sturdy torsion beam design for dependable long life and accuracy. The small frame model offers working ranges from 3 in. lbs. to 50 ft. lbs. in 1/4" and 3/8" drives. The large frame model continues from 100 ft. lbs. through 2,000 ft. lbs. with 1/2", 3/4" and 1" drives. Accuracy of both series of ? 4% meets or exceeds ASME B107.14-1994, ISO 6789 bi-directionally from 20% to 100% of scale. All wrenches supplied with a N.I.S.T. traceable certificate of calibration.
Features:
- Sturdy body construction insures durability
- Easy to read laser marked dual scale
- Large easy to read dial is shock resistant and protected by a tough metal guard
- Memory needle retains highest torque reading applied
- Calibrated in both cw and ccw direction
- Accuracy: ? 4% of indicated value, cw & ccw, from 20% to 100% of full scale
- Individually serialized with matching certifi cate of calibration traceable to N.I.S.T.
- Electric Signaling Model
- Image is representative and may not depict the actual product.
Specifications:
- Torque Range: 0-600 ft. lb.
- Increments: 10 ft. lb.
- Length: 47"
- Weight: 9.25 lbs.
- 6004LDFESS includes 1 Extension handle, indicating light and buzzer.
A 15% restocking fee is charged to return this item (unused).
CDI 6004LDFESS 3/4" Drive Dial Torque Wrench with Light 0-600 ft-lbs/b>
