R-12 & R-134a Deluxe Leak Seeker Detector

The CPS Products LS790B R-12 & R-134a Deluxe Leak Seeker® Detector is a portable, handheld refrigerant leak detector that features 10 sensitivity ranges, LED display, automatic calibration, low battery indicator, and 18" flexible probe. It is the only portable refrigerant leak detector with 10 different sensitivity ranges for effectively locating all refrigerants, large or small. At the lowest sensitivity setting, the LS790a can detect an HFC-134a leak as small as 1/2oz. (15grams) per year. At the highest sensitivity setting, the unit can detect an HFC-134a leak as small as 1/4oz. (10grams) per year.

The LS790B features a clear button that clears the memory in the microcomputer and recalibrates to ambient. It also has a lock-out mode that measures and records the highest level detected by the Ion-Pump™. The alarm sounds a two-tone signal and the visual display flashes when the recorded high has been detected, "locking out" all background contamination.

The LS790B has an alarm select feature that allows you to select audible alarm, visual indicator, or both. It also has a 10 position moving LED display that indicates varying halogen concentrations. As the concentration increases, the LED moves left to right. In the Lock-OutT mode of operation, the LED's flash only at the leak source.

The LS790B has a low battery indicator that constantly illuminates at half brightness when batteries are low. It also has an 18" flexible probe that easily twists and turns into otherwise inaccessible areas. You're in and out in less time, with no coiled cord to tangle.

The LS790B has a power saver feature that automatically switches power off after 15 minutes of use. This extends battery life.

The LS790B also features a super-sensitive Ion Pump™. This pump has no moving parts, valves or fans. It provides an extremely precise flow of air through the sensor chamber. The LS790B is the only field replaceable Ion-pump sensor in the industry.

The CPS Products LS790B R-12 & R-134a Deluxe Leak Seeker® Detector is a versatile and reliable tool that is perfect for HVAC technicians, automotive technicians, and other professionals who need to detect refrigerant leaks. It is easy to use and has a variety of features that make it an excellent choice for any application.

Key Features:

• Variable Sensitivity: The only portable refrigerant leak detector with 10 different sensitivity ranges for effectively locating all refrigerants, large or small.
• Clear: Clears the memory in the microcomputer and recalibrates to ambient.
• Lock-Out™: Selects Lock-Out™ mode; measuring and recording the highest level detected by the Ion-Pump™. The alarm sounds a two-tone signal and the visual display flashes when the recorded high has been detected, "locking out" all background contamination.
• Alarm Select: Selects audible alarm, visual indicator, or both.
• Visual Indicator: 10 position moving LED display indicates varying halogen concentrations. As the concentration increases, the LED moves left to right. In the Lock-OutT mode of operation, the LED's flash only at the leak source.
• Low Battery Indicator: The low battery LED constantly illuminates at half brightness when batteries are low.
• 18" Flexible Probe: The metal cable probe easily twists and turns into otherwise inaccessible areas. You're in and out in less time, with no coiled cord to tangle.
• Power Saver: Automatically switches power off after 15 minutes of use. Extends battery life.
• Super-Sensitive Ion Pump™: No moving parts, valves or fans. Provides an extremely precise flow of air through the sensor chamber. The only field replaceable Ion-pump sensor in the industry.

Applications:

• HVAC
