Load
Genie
A load genie is a combination un-loader and check valve. Unloads
discharge manifold in either vertical or horizontal position of any
compressor when compressor cycles and flow stops. Efficient,
quiet, economical and eliminates tubing/fittings of conventional
pressure switch un-loader.
Features:
- Maximum working pressure:
250 PSI
- Maximum recommended
compressor speed: 400 RPM
- Maximum recommended
temperature: 450° F
- Made of brass, stainless
steel spring, fluorocarbon piston seal, teflon seals
Specifications:
- 1/4" Female NPT
Inlet
- 1/4" Male NPT Outlet
- 1-6 SCFM Range
