Circuit Load Simulator

Motor Magazine 2008 Top 20 Tools Winner

Eliminate unnecessary component replacement and the inaccurate method of static voltage testing vehicle wiring with a DVOM. The Circuit Load Simulator is like using a KNOWN GOOD component to dynamically LOAD TEST the circuit.

Four Easy Steps to Test a Circuit
  1. Disconnect the suspect component and connect the simulator to the vehicle connector.
  2. Select the type of load to simulate and press START.
  3. Activate the test circuit, in seconds the unit dynamically load tests power and ground wiring.
  4. View the results: "good", "bad" or "suspect", the measured voltage drop and "loaded ohms" reading.
Safe for computer controlled circuits.

You can use the simulator to test the following circuits and more:
  • fuel pump
  • engine cooling fan
  • windshield wiper
  • power window
  • power door lock
  • HVAC blower
  • side mirrors
  • sun / moon roof
  • 4x4 actuator
  • low beam headlamp
  • high beam headlamp
  • brake / park lamps
  • HID ballast
  • AC clutch
  • rear window defogger
  • accessory port (cigar lighter)
  • horn
  • glow plug (single)
  • heated seat
Waekon 44065 Circuit Load Simulator

$287.53

This product has been discontinued

This product was added to our catalog on Friday 19 December, 2008.
