8KW Infrared Curing System w/ Sensor

Short Wave Infra-Red Curing System

• Eight (8) 1,000 watt infrared short wave lamps on 2 independently adjustable heads provide the maximum 3,081 sq. in.(2m?)cure area. Cure area is uniform and focused with no hot or cold spots. Each array of 4 lamps may be adjusted to conform to the contour of the panel.
• Thermal Integrated Sensor System (TISS) allows for fast set up and automatic regulation: Distance sensor emits audible tone for setting the proper distance from the panel. Heat sensor automatically adjusts the temperature throughout the curing process.
• Cures on any substrate. Cures primer in 3 to 8 minutes, water based filler in 7 to 9 minutes.
• Modulated ramp-up time for maximum control and heat transfer.
• Auto Timed Shut-Off: Reduces chance of damage to finish due to overheating.
• Heavy duty stand with movable arm and a locking caster allows the lamp head to be positioned to panels from the rocker to the vehicle roof. (Note: Appropriate 220 volt plug must be installed by user.)

$85 standard freight fee.

Herkules 8000S 8KW Infrared Curing System w/ Sensor
