DIAL INDICATOR XXX

Specifications

• Manufacturer: Fowler High Precision Fowler FOWLER
• Model Number: 72-520-110
• Product Name: DIAL INDICATOR XXX Fowler DIAL INDICATOR XXX Fowler 0-1" Dial Indicator
• Weight: 0.35 lbs
• Dimensions: 6.5 x 3.1 x 2.2 inches

Key Features

• Revolution Counter Hand: Ensures precise tracking of spindle rotations for accurate measurements.
• Lug Backs Positioned at 90-Degree Increments: Provides secure and stable mounting options for various applications.
• Spindle Rack and Contact Points: Made from hardened stainless steel for extended durability and precision.
• Gear Wheels: Constructed from hard brass and lapped for smooth, noise-free operation.
• Pinions: Crafted from silver steel, hardened, tempered, and burnished on pivots for long-lasting performance.
• Microfine Graduations: Blackened graduations for continuous readings and red markings for balanced readings.
• Independent Movement Mounting: Mounted on a rigid supporting plate to ensure perfect alignment between the movement and case.

Applications

The Fowler 0-1" Dial Indicator is ideal for precision measurement in machining, toolmaking, and quality control applications. It’s commonly used for checking part dimensions, verifying machine performance, and ensuring accuracy in manufacturing processes. Its compact design makes it suitable for use on lathes, milling machines, and other shop floor equipment.

Benefits

• Enhanced Precision: The hardened stainless steel spindle rack and contact points ensure long-lasting durability and accurate measurements.
• Ease of Use: The revolution counter hand simplifies tracking spindle rotations, making it easier to achieve precise results.
• Versatile Mounting Options: With lug backs positioned at 90-degree increments, the indicator can be securely mounted in various orientations for different applications.
• Durable Construction: High-quality materials like forged brass and hardened silver steel ensure long-term reliability and performance.
• Improved Readability: Microfine blackened graduations provide clear and continuous readings, while red markings offer balanced reading capabilities.

This product is designed to meet the demands of precision measurement in industrial settings, offering both accuracy and durability for a wide range of applications.
