GPC 2500 with Welder, AC Generator & Air Compressor

Power Equipment for your Service Vehicle All-in-one designed to meet the needs of today's mobile service mechanics- providing air poer, AC power and DC welding.

Hydraulic Requirement

• 10 GPM @ 2500 psi – 15 GPM @ 3000 psi tandem pump
• 35 gallon (minimum) hydraulic tank
• Requires (2) 3/4" pressure lines (minimum), 1" return hose (minimum)

DC Welding

DC Stick 40 - 250 amp – 225 amp 60% duty cycle

Cables

25 ft. 1/0 ga. welding cables included

AC Power

6000 watt 60 hz (while not welding), Synchronous, brushless, AC generator

Outlets

• one 120 volt, 20 amp duplex outlet
• one 120 volt, 30 amp twist lock outlet
• one 240 volt, 20 amp twist lock outlet

Air Power

• 2 stage 24 CFM @ 100 psi, 150 psi max
• Air gauge on control panels monitors air tank pressure

Air tank required, sold separately.

Control Panel

Standard 12 ft. cable harness

Control Box Dimensions

18"W x 5"D x 12"H

Installation

• Provides for a compact, easy installation in less time with these simple bolt-in packages
• Center point lift included for easy installation
• Standard remote mount control box

Options & Accessories

• 50-08750 ft. Welding Cable Upgrade
• 61-13030 gallon Vertical Mount Air Tank
• 61-13130 gallon Horizontal Mount Air Tank
• 50-44312 gallon Horizontal Mount Air Tank
• 990-200Factory installed stand and 30 gallon Air Tank Kit

545 Lbs $85 standard freight fee. Applies to direct shipping points within the 48 continental US states. Rural Area Surcharge may apply.

• *An additional $40.00 will apply to all residential deliveries of heavy-equipment.
• *For lift-gate service, add $135.00.

Manufacturer drop ship.

Goodall 02-500 GPC 2500 with Welder, AC Generator and Air Compressor
