Internal Spring Compressor, short, Size 1 + 2

Features and Benefits:

• Universal fit.Especially suitable for Chrysler, Mercedes, etc.
• For a secure installation and removal of chassis springs
• 3-point safety lock
• Automatic free-wheel
• Spindle overload protection
• Universal fit.Especially suitable for Chrysler, Mercedes C-Class (W202), CLK (W208), E-Class (W210, W211), S-Class (W140), SL (R107, R129, R170), W114, W115, W116, W123, W124, W126, and W201 for rear axle springs. Also fits BMW 1 Series (E87) and 3 Series (E90) if used in combination with pressure plates KL-0025-16.
• Code: 3402495
• Part No.: KL-0025-20 E
• Spring ? min. (inner): 75 mm
• Spring ? max. (outer): 140 mm
• Working Travel: 177 mm
• Clamping width (min.): 110 mm
• Clamping width (max.): 287 mm
• Outer ?, Cylinder: 44 mm
• Load (max.): 30.000 N
• Drive (waf): 19 mm
• Storage: in Foam Insert
• Width: 370 mm
• Depth: 231 mm
• Height: 90 mm
• Contents: 1 tlg.
• Weight: 4,5 kg



Enables the removal of the rear axle springs in case of confined spaces without lowering the rear axle beam. Pros: 3-Point safety lock Automatic free-wheel Corrugated profile Spindle overload protection
