Digital UV C Meter

This instrument is designed to measure ultraviolet light in the range from 220 to 275 nanometers (UVC). The illumination range of the meter allows users to conduct the most precise quantitative measurements of ultraviolet radiation: radiometry and laboratory requirements, UV-curing in off-set printing, lamp UV intensity & aging, industrial process monitoring, semiconductor fabrication, sunlight UV intensity to prevent skin damage, sterilization and environmental monitoring.

Features:

• Backlit LCD with 4 digit dual display
• High and Low measurements
• Range in a unit mW/cm2 or uW/cm2
• Socket for tripod mounting
• Automatic measuring
• Low battery indicator
• Magnetic mount
• 20 point memory
• Over Range Indication
• Zero Adjust
• Auto Record
• Includes Certificate of Traceable Calibration
• ROHS, CE, WEEE

Includes:

• 1 "9V" battery
• UV sensor probe
• Instruction Manual
• Hard carrying case

Specifications:

• Spectrum Range: 220 ~ 275 UVC
• Calibration Point: 254 nm UVC
• Illumination Range:
  • Low: 1 uW/cm2 ~ 1999 uW/cm2
  • High: 0.01 mW/cm2 ~ 40.00 mW/cm2
• Accuracy: 23 ?5° (73.5 ?9°) ?4% ?1 digit
• Sample Time: Approx. 0.3 sec.
• Memory: 20 points and 1 for interval time
• Operation Temperature: 32? to 122° (0? to 50°); 10~90% RH
• Weight: Approx. 3.2oz (90g)
• Dimension: 5.51" x 1.93" x 1.14" (140 x 49 x 29 cm)
• Power Source: "9V" battery (included)

Certificate of Traceable Calibration

This instrument has been calibrated in accordance with General Tool's strenuous calibration procedures during the manufacturing process, established specifically for the manufacture of test instruments.

General Tools & Instruments further certifies that this instrument meets or exceeds published measurement specifications (unless otherwise noted) and has been calibrated using standards traceable to the National Institute of Standards and Technology (NIST/USA) or the National Measurement Laboratory R.O.C (NML/ROC).

Product Dimensions:

• Length (in): 5.51
• Weight (lbs): 3.2 oz
• Width (in): 1.93
• Height (in): 1.14

General Tools & Instruments UV512C Digital UV C Meter
