10" Contour Gauge

The General Tools & Instruments 10" Contour Gauge (833) is a precision measuring tool used to create templates for duplicate curves or shapes. It features a 10" long, flexible, aluminum beam with a 1" wide strip of 1/32" thick steel along the center. The steel strip is graduated in 1/16" increments, and the beam is marked with a series of holes spaced 1/8" apart. A locking thumbscrew at one end of the beam secures the steel strip in place, and a spring-loaded plunger at the other end allows the user to create templates of any shape.

Key Features:

• 10" long, flexible aluminum beam
• 1/32" thick steel strip graduated in 1/16" increments
• Series of holes spaced 1/8" apart
• Locking thumbscrew
• Spring-loaded plunger

Applications:

• Creating templates for duplicate curves or shapes
• Patternmaking
• Drafting
• Woodworking
• Metalworking

Benefits:

• Accurate and precise measurements
• Easy to use
• Durable construction
• Versatile

The General Tools & Instruments 10" Contour Gauge (833) is a valuable tool for any professional or hobbyist who needs to create templates for duplicate curves or shapes. It is accurate, easy to use, and durable.
