AC/DC Digital Clamp On Multimeter

Where accuracy, quality, and newest technology meet. The APBACDC-100 offers superior AC/DC measurement capabilities, highest product quality and enhanced ergonomics with Red, Rubber, Ribs™ design.  With relative zero mode, auto power off, audible continuity and accommodates conductors up to 2.00" in diameter. "Third hand" test probe holder. Rubber over-molded case with built in probes storage. Comes with carrying case, test leads, batteries (installed) and user manual.

Features:

• Large, easy to read LCD display
• Auto and manual ranging
• Data hold
• MAX capture function for inrush current measurements (30 mS response)
• Diode test

Specifications:

• DC Current: 400.0 / 1000 A
  Accuracy: +/-(1.5% Rdg + 4 LSD) @ 0 to 800A **
• AC Current: 400.0 / 800 A
  Accuracy: +/-(1.5% Rdg + 5 LSD) @ 0 to 600A, 40 to 100Hz **
• AC Voltage: 400.0 mV 4.000 / 40.00 / 400.0 / 600V
  Accuracy: +/-(1.5% Rdg + 4 LSD) @ 4V to 400V ranges , 50 to 500 Hz**
• DC Voltage: 400.0 mV 4.000 / 40.00 / 400.0 / 600V
  Accuracy: +/-(0.5% Rdg + 3 LSD) @ 4V to 400V ranges **
• Resistance: 400.0 Ohms 4.000 / 40.00 / 400.0 kOhms 4.000 / 40.00 MOhms
  Accuracy:: +/-(0.6% Rdg + 4 LSD) @ 4 to 400 kOhms ranges **
• Capacitance: 500.0nF / 5.000 / 50.00 / 500.0 / 3000 uF
  Accuracy:+/-(3.5% Rdg + 6 LSD)

Amprobe ACDC100 AC/DC Digital Clamp On Multimeter
