Digital Mini Multimeter

Electronic Specialties | Digital Mini Multimeter | 501

The ESI 501 Digital Mini Multimeter is a compact, portable, and affordable multimeter that is perfect for a variety of electrical testing applications. It features a 3 1/2 digit LCD display, 16 test ranges, 6 functions, and a protective holster. The 501 is also fuse protected, has safety leads and jacks, and a removable test leads.

Key Features

• 3 1/2 digit LCD display
• 16 test ranges
• 6 functions
• Fuse protected
• Safety leads and jacks
• Removable test leads
• Protective holster

Applications

The ESI 501 Digital Mini Multimeter can be used for a variety of electrical testing applications, including:

• Voltage measurement
• Current measurement
• Resistance measurement
• Diode testing
• Continuity testing
• Battery testing

Benefits

The ESI 501 Digital Mini Multimeter offers a number of benefits, including:

• Compact and portable design
• Affordable price
• Easy-to-use interface
• Durable construction
• Wide range of test functions

Technical Specifications

• Testing Ranges:

  • DC Volts: 0-200mV, 2000mV, 20V, 200V, 500V
  • AC Volts: 0-200V, 500V
  • DC Amps: 0-2mA, 20mA, 200mA
  • Ohms: 0-200 Ohms, 2000, 20K, 200K, 2000K
  • Battery Test: 0-9V
  • Diode Test: 0-2000 Ohms

• Accuracy:

  • DC Volts: ±0.5%
  • AC Volts: ±1.0%
  • DC Amps: ±2.0%
  • Ohms: ±2.0%
  • Battery Test: ±1.0%
  • Diode Test: ±5%

• Resolution:

  • DC Volts: 1 mV
  • AC Volts: 1 mV
  • DC Amps: 0.01 mA
  • Ohms: 1 Ohm
  • Battery Test: 1 mV
  • Diode Test: 1 Ohm

• Auto Power Off:

  • 15 minutes

• Dimensions:

  • 130mm (L) x 70mm (W) x 35mm (H)

• Weight:

  • 150g

To learn more about the ESI 501 Digital Mini Multimeter, please visit our website.
