True-rms Clamp Meter 320 Series FLU324

Non-stock item, back order status; please email service@toolsource.com for cost and lead time (usually several weeks).

True-rms measurements and optimized ergonomics make the 320 Series Clamp Meters the best general troubleshooting tools for commercial and residential electricians. The 323, 324 and 325 are designed to verify the presence of load current, AC voltage and continuity of circuits, switches, fuses and contacts. These small and rugged clamp meters are ideally suited for current measurements up to 400 A in tight cable compartments. The Fluke 324 model also includes temperature and capacitance measurement capabilities.

Measurement capability:

• 400 A ac current measurement
• 600 V ac and dc voltage measurement
• True-rms ac voltage and current for accurate measurements on non-linear signals
• Resistance measurement up to 40 k? with continuity detection
• Temperature and capacitance measurement

Features:

• Slim, ergonomic design
• Large, easy to read backlight display
• CAT IV 300V/CAT III 600 V safety rating
• Hold button
• Two-year warranty
• Soft carrying case

Specifications:

Specifications
AC current	Range	40.00 A/400.0 A
	Accuracy	1.5 % ? 5 digits (45 Hz to 400 Hz) Note: Add 2 % for position sensitivity
DC current	Range	-
	Accuracy	-
AC voltage	Range	600.0 V
	Accuracy	1.5 % ? 5 digits
DC voltage	Range	600.0 V
	Accuracy	1.0 % ? 5 digits
Resistance	Range	400.0 ?/ 4000 ?
	Accuracy	1.0 % ? 5 digits
Continuity		<= 30 ?
Capacitance		100.0 ° to 1000 °
Frequency		-
AC response		True-rms
Backlight		Yes
Data hold		Yes
Contact temperature		-10.0 ° to 400.0 ° (14.0 ° to 752.0 °)
Min/Max		-
Size	H x W x D (mm)	207 x 75 x 34
	Max wire diameter	30 mm (600 MCM)
	Weight	208 g
Category rating		CAT III 600 V CAT IV 300 V
Manufacturer Warranty		Two-year

Fluke 324 True-rms Clamp Meter
