Single Acting Spring Return Ram - 25 Ton Cap w/ 6 1/4 In Stroke

OTC 4106 Features:

  • Oil capacity: 32.2 cu. in.
  • Effective Ram Area: 5.157 sq. in.
  • 25.8 tons at 10,000 PSI.
  • Spring return.
  • Collapsed height 13 3/8".
  • Extended height 19 5/8".
  • Piston protrusion at collapased height: 1 7/8".
  • Piston thread: 2" NPT.
  • Collar thread: 3 5/16"-12 straight.
  • Internal base thread: 2"-11 1/2" NPSM.
  • Designed & tested to meet ANSI B30.1.
  • Additional bearing surface has been designed into unit to effectively resist the punishing stress exerted by off center loads.
  • Weight: 26 lbs.

OTC 4106 Single Acting Spring Return Ram - 25 Ton Capacity with 6 1/4" Stroke

Usually In Stock
Usually ships in 24-48 hours
Manufacturer Direct

$1,014.85

This product was added to our catalog on Friday 16 February, 2007.
