Product Features
- 15 Amp motor quickly rips through hardwoods with ease
- Rack and pinion fence rails make fence adjustments fast, smooth and accurate
- Telescoping fence rails retract to create a small, portable package
- 16" of rip easily cuts a variety of larger shelving and trim materials
- Metal roll cage base offers greater durability than plastic bases
- Blade can be adjusted 0 - 45 degrees for bevel applications
- Table coating reduces friction for smoother cutting
- Weighing only 45 lbs, the DW745 can easily be moved on and off the job
- 24T carbide blade enhances cut quality and prolongs blade life
- Dust port allows for 2-1/2" vacuum hook up and minimizes clean up
- Adjustable rear feet designed to level the saw on uneven work surfaces
Specifications
| Amps |
15Amps |
| No Load Speed |
3,850rpm |
| Blade Diameter |
10" |
| Arbor Size |
5/8"" |
| Dust Port Diameter |
2-1/2" |
| Depth of Cut at 90° |
3-1/8" |
| Depth of Cut at 45° |
2-1/4" |
| Max Rip To Right Of Blade |
16" |
| Max Rip To Left Of Blade |
12" |
| Max Width of Dado |
N/A" |
| Tool Weight |
45lbs |
| Shipping Weight |
53lbs |
The DW745 Includes:
- Miter Gauge
- Push stick
- 10" 24T Carbide Blade
- Blade Guard
DeWalt DW745 10" Compact Job Site Table Saw
