1-3/4 HP (Maximum Motor HP) Router

1-3/4 HP (Maximum Motor HP) Router  690LR

The 690LR includes Router Motor, Fixed Base, 1/4" & 1/2" collets, Collet wrench, Operating manual.

Features:

•11 Amp motor producing 1-3/4 Peak HP


•27,500 rpm single speed motor


•Cam lock lever enables simple coarse height adjustments and motor release (fixed base)


•Micrometer depth adjustor accurate to 1/128"


•Dust-sealed switch and sealed ball bearing construction enhance tool durability


•Precision machined aluminum motor housing and base


•Auto-release collet system allows for easy bit removal after use


•Collets included to accept 1/4" and 1/2" shank bits


•Under table stop prevents motor from inadvertently rotating out of base


•Overmolded grips for greater comfort in extended use

Specifications:

•Power: 120 VAC, 25-60 HZ


•Horsepower: 1-3/4 HP


•Amps: 11 Amps


•No Load Speed: 27,500 rpm


•Motor Diameter: 3-1/2 "


•Collets: 1/4" & 1/2" "


•Base: 5-3/4" Round


•Switch:


•Length: 12 "


•Width: 5.5 "


•Height: 8-5/8 "


•Weight: 8 lbs


•Shipping Weight: 10 lbs

Porter-Cable 690LR 1-3/4 HP (Maximum Motor HP) Router
