The AFF model 859SD 100 Ton Shop press with it's welded frame and heavier gauge steel make this press ideal for heavy duty truck applications, spring shops, industrial, or every day shops that find themselves in need of a "step up" from a regular duty press.
New and Improved!- Added Bed Winch System speeds up bed adjustment
- Completely redesigned side to side movement of press head
- Completely redesigned Hydraulic Power Unit increases operating speed dramatically over old style.
- Comes with an adjustable / removable pressing guard for added operator safety.
- Includes large liquid filled gauge positioned so the operator can safely monitor pressing force being applied.
- Included 10 piece bearing press adapter kit.
- Pressing head moves side to side to accommodate off centered pressing requirements.
- Includes 2 pc combination pinned V-block / press plate set.
- Integral bed positioning raises and lowers the bed effortlessly using the ram.
- Operated manually or by air motor assist with foot control.
- Dual Air Motor operation for pressing and retraction speeds up pressing process.
- Welded frame for added strength.
- 7 Position bed height configuration adds greater flexibility.
- Overload protection adds operator safety and prevents damage from over pressurizing.
- Highpoint relief valve prevents ram from being overextended.
- 4 Press bed pins incorporate a "butterfly" lock to keep press bed pins engaged for greater safety.
Specifications:- Ram Stroke: 11.8"
- Hydraulic system pressure: 9237 psi
- Air Pressure: 110 to 120 psi
- Overall Width: 55"
- Overall Height: 84"
- Bed Depth: 13.5"
- Bed Width: 31"
- Throat Depth: 9"
- Throat Width: 16.5"
- Bed Positions: 7
- Hole Distance (ctr to ctr): 5.5"
- Net Weight: 1476 lbs. (671 kgs)
