Super Duty Shop Press 20 Ton

Air or Manually operated the 850SD - 20 Ton Super Duty Shop Press, is geared towards either the more active Professional Automotive shop or the Industrial customer with lighter requirements for a shop press.
  • Comes with an adjustable / removable pressing guard for added operator safety.
  • Includes large liquid filled gauge positioned so the operator can safely monitor pressing force being applied.
  • Included 10 piece bearing press adapter kit.
  • Pressing head moves side to side to accommodate off centered pressing requirements.
  • Includes 2 pc combination pinned V-block / press plate set.
  • Operated manually or by air motor assist with foot control.
  • Welded frame for added strength.
  • 10 Position bed height configuration adds greater flexibility.
  • Overload protection adds operator safety and prevents damage from over pressurizing.
  • Press bed pins incorporate a "butterfly" lock to keep press bed pins engaged for greater safety.
Specifications:
  • Capacity: 20 Tons
  • Ram Stroke: 7.5"
  • Hydraulic system pressure: 9237 psi
  • Air Pressure: 110 to 120 psi
  • Overall Width: 35"
  • Overall Height: 64"
  • Bed Depth: 7"
  • Bed Width: 19.25"
  • Throat Depth: 5.75"
  • Throat Width: 10.75"
  • Net Weight: 282 lbs.
$85 standard freight fee. Applies to direct shipping points within the 48 continental US states. Rural Area Surcharge may apply.
  • *An additional $40.00 will apply to all residential deliveries of heavy-equipment.
  • *For lift-gate service, add $135.00.
Manufacturer drop ship.

American Forge & Foundry AFF 850SD 20 Ton Super Duty Shop Press

$1,610.84

This product has been discontinued

This product was added to our catalog on Tuesday 17 July, 2012.
