LeakMaster Evaporative Emissions System Tester / Smoke Machine

LeakMaster`s simple two-step process makes testing today`s most advanced OBD-II systems quick and easy.

• You simply connect the unit to the vehicle`s EVAP service port and battery. The OTC LeakMaster 6525 can be calibrated to identify leaks at .020 and .040 (thousandths of an inch). There is a feature setting on the control valve making it capable of detecting leaks much smaller than .020, allowing the unit to keep pace with testing standards as they change. The LeakMaster indicates, with a Pass/Fail, if the system being tested has unacceptable leakage. There is not more guess work.

With LeakMaster, when you see the smoke, you`ve found the leak!

• If the LeakMaster confirms the existence of excessive leakage in the system, simply switch the unit into phase-two testing, which introduces non-toxic diagnostic smoke with UltraTraceUVT technology. Locating the area of any leak is simple, just look for the smoke exiting at the point of leakage. The UltraTraceUVT dye will help you pinpoint the exact point of any leak during and after testing.

A truly versatile unit for testing a wide range of systems.

• The LeakMaster is designed to work with either nitrogen or shop air. In addition to its EVAP capabilities, the LeakMaster also locates wind and water leaks, vaccum/induction leaks, climate control vacuum leaks, exhaust leaks, and many other closed system leaks. And, all testing is safely performed with the engine off.

Specifications:

• Dimensions: 23" H x 18" W x 9-1/2" D
• Weight: 20 lb.
• Power Supply: 12-volt DC
• Amperage Usage: 15 amps
• Supply Pressure: 13.0 in. H20
• Supply Volume: 15 liters per minute
• Operating Temp. Range: 45? F to 140? F
• Air Supply Line (Clear): 12 feet
• Smmoke Supply Line: 12 feet
• Power Supply Line: 12 feet
• Remote Starter Cable: 12 feet

Accessories: (Included with 6525; also available separately)

• CEA-01 3-1/2" Diameter Exhaust Cone (Qty. 2)
• CEA-02 Assorted Cap Plug Kit
• CEA-03 Smoke Diffuser Adapter
• HS-400AC 400,000 CP Spotlight with 20 ft. Cord and Battery Clips
• CEA-04 Standard SVC Port Adapter
• CEA-041 25 ft. Nitrogen Coiled Hose
• CEA-042 Small SVC Port Adapter
• CEA-049 Doulbe Ended Schrader Remover Tool
• SR00 Water Trap Filter
• P-0716-UV Smoke Compound w/UltraTrace UVT Techonology

OTC 6525 LeakMaster Evaporative Emissions System Tester
