The Wall Lenk Cordless Battery Powered Solder Iron is a portable solution for soldering when electricity is not an option. This 15W iron uses 4 1.5V alkaline AA batteries (not included) and reaches a maximum temperature of 1050°F. It features a long life, iron-plated anti-corrosion tip and a built-in LED light to illuminate your work area.
Key Features:
- Develops maximum 1050°F tip temperature
- Reaches 365°F in about 7 seconds
- Operates for approximately 50 minutes of continuous use with fresh batteries
- Will complete approximately 160 solder joints with fresh batteries
- Has a long life, iron-plated anti-corrosion tip
- Lightweight - about 5 ounces with batteries (less than 3 ounces without)
- Built-in LED light illuminates work area
Applications:
This solder iron is ideal for a variety of applications, including:
- Fine Wiring - intricate soldering, printed circuit boards, marine wiring, CB's, ham radios, field service requests
- Electronics - TVs, radios, stereos, computers, games and toys
- Hobbies - model building, model railroads, radio control (r/c) models, slot and scale cars and jewelry making
Benefits:
- Portable - no electricity required
- Lightweight and compact
- Long battery life
- Durable construction
- Affordable
Instructions:
- Insert 4 1.5V alkaline AA batteries (not included) into the battery compartment.
- Turn the power switch to the "On" position.
- Allow the iron to heat up for about 7 seconds.
- Apply solder to the tip of the iron.
- Touch the hot tip to the solder joint to melt the solder.
- Once the solder has melted, remove the iron from the joint.
- Turn the power switch to the "Off" position.
Cautions:
- Use carefully. The tip is extremely hot during use. Avoid contact with hands, skin and other objects.
- Use only in well ventilated areas.
- Hot irons can cause severe burns. Do not touch the heated tip or knurled nut.
- Not a toy. Store out of the reach of children.
- Always be sure the unit is cool before storing.
- Do not replace cap without switching unit off and ensuring tip has cooled.
- Do not attempt to readjust or repair. Unit is not user serviceable.
- When replacing batteries, replace all of the batteries with the correct type.
- Do not mix new batteries with used batteries or batteries of a different type.
- Be sure to insert batteries properly (+/-).
- Be sure to remove the batteries before storing the unit.
