3/4 Inch Digital Torque Tester DTT 60-600 ft-lbs 81.35-813.5 Nm,

Test the health of your torque wrenches, anywhere with the Digital Torque Tester™, utilizing the testing protocol and standards developed by the American Society of Mechanical Engineers (ASME)

The Digital Torque Tester™ (DTT) is designed to be an affordable torque tester that can be mounted on a wall or used in a bench-top vise to allow the operator to conveniently test torque wrenches and torque screwdrivers. It features an easy to use touch pad screen to capture peak torque values during a test in real time, and download stored torque data to a PC. All DTT torque testers are sold in a kit with the complete tester, hard carrying case, a socket driver reducer adapter and AC/DC power supply.

Features:

• Integral Transducer and sturdy housing allow mounting in virtually any position
• Integral Transducer: Full bridge strain gage, 350 ohm, 1500uE, 3mV/V F.S, 3.75 excitation.
• Units of Torque: Nm, kgcm, ft-lbs in.lb., in-oz.
• Audible (tone) and LED light-bar Present Alerts
• Torque Accuracy: ?0.5% ?1 count CW and CCW from 10 to 100% of full scale at 25? C
• LCD Touch Screen: 4.7 in. color graphics display
• Screen resolution: 480 X 272 pixels
• Display Accuracy: 4 digits, 9999 cycle counts
• Six "AA" Alkaline cells for battery power included
• Track, Peak and First Peak modes of operation
• Operating Temperature: 40 to 110? F (5 to 42? C)
• Storage Temperature: 0 to 122? F (-20 to 50? C)
• Humidity up to 85% non-condensing
• EU/CE-DE, ES, FR, IT, NL, PT, UK and Japanese language manual
• Certifi cate of N.I.S.T. traceability from 10% to 100% of full scale
• Includes storage case, AC adapter and USB cable
• Made in U.S.A. for automotive, industrial, or general purpose use.

Specifications:

• Female Drive: 3/4"
• Range English: 60-600 ft-lbs/li>
• Range, Nm: 81.35-813.5
• Range, kgcm: 8.3-82.95 kgm
• Accuracy: ? 0.50% 10% to 100% CW & CCW of indicated test value @ 25? C (Except 2503 -F-DTT)
• Units of Measure: Nm, kgcm, ft-lbs in.lb., in.oz., kgm, cNm
• Operation Modes: TRACK, PEAK, FIRST PEAK
• Operating Temperature: 10 to 32? C (50 to 90? F)
• Storage Temperature: -20 to 50? C (-2 to 122? F)
• Humidity: 85% Relative Humidity @ 21? C (70? F)
• Power Supply: Included 9-volt A/C D/C adapter. 6 AA batteries included.
• Data Storage/Recall: Memory Capacity - 500 Records (Complete Check Mode Only.)
• Dimensions: W - 10" x H - 16" x D - 2.5"
• Weight: (Tester Only) - 10.7 lbs., (with Carrying Case) - 17.4 lbs.

A 15% restocking fee is charged to return this item (unused).

J H Williams 6004-F-DTT Digital Torque Tester™ (DTT)
