Proudly made in the USA, the Machinist round channel vise is designed
to handle the most demanding clamping applications. Unlike most vises
that have a fixed center nut the Machinist round channel vise nut is
anchored at the rear. This rear anchored nut provides straight line
pull and even pressure resulting in greater durability. The round
channel design also allows for a completely enclosed spindle and nut
assembly. This enclosure keeps debris out and lubrication in for a
lifetime of smooth operation. The Machinist vise is equipped with main
jaws and a machined anvil work surface. The main jaws are made from
high strength steel and are fully replaceable. The Machinist vise is
also equipped with a swivel base with dual locking nuts. The open
locking design of the Machinist base allows for a full 360 degrees of
rotation. To prevent rotation during use both the locking nuts and base
have serrated edges that interact positively to assure a non-slip grip
when tightened. The main base has four pre-cast holes for mounting the
vise to a work surface. Each vise includes a mounting template for
quick no guess hole placement for mounting.
Hardened
steel jaw, replaceable inserts are machine serrated for safe, sure grip
under maximum torque. Extra deep throat - this design gives you more
working room where it counts. Enclosed design keeps lubrication in and
contaminants out for smooth operation. Locking swivel base - 360 degree
rotation is enhanced by serrated swivel base with double lockdowns for
non-slip holding and four mounting posts. Large anvil work
surface.
- Model
Number: 300S
- Brand:
Wilton
- Height:
6.7"
- Width:
6.8"
- Length:
15.2"
- Net
Weight: 29.25 lb
- Gross
Weight: 29.25 lb
- Jaw
Depth: 1/2"
- Jaw
Height: 3/4"
- Jaw
Width: 3"
- Opening
Capacity Max: 4-3/4"
- Serrated
Jaw Inserts #: 2903080
- Throat
Depth: 2-5/8"
- Type
of Base: 360 Degree Swivel
- Type
of Nut: Straight Line Pull
- Smooth
Jaw Inserts #: 2903090
- Center
Distance: 2"
- Bolt
Circle Diameter:6-3/8"
Wilton
Tools 10006 300S Machinists' Bench Vise with Swivel Base, 3"
Jaw Width, 4-3/4" Jaw Opening & 2-5/8" Throat Depth
