Product Specifications
Input Voltage: 120V AC
Input Current: 15A cont/24A int
Output Voltage: 12V
Output Current: Service/13.5V, 0-70A; Boost/14.4V, 0-70A; Flash/13-14.8V, 0-70A cont, 100A int
Dimensions: 17.88 × 17.76 × 5.55 in
Weight: 19.35 lb
Safety Certifications: UL ULC
Warranty Period: 1 year
Unit features
Fully automatic microprocessor controlled power supply
For regular automotive, lead-acid, calcium, AGM, start-stop and Gel Cell battery types
Maintains stable voltage under varying loads during major vehicle ECU reprogramming and diagnostic work
Digital volts and amps display
Multiple output cable selection
Anderson plug with interchangeable power cords for different regional users
Heavy-duty replaceable clamps
Large handle
Adjustable mounting brackets
Adjustable mounting brackets for easy permanent installation to most shop vehicle lifts
Dual temperature-controlled cooling fans
Durable aluminum case
Power supply features
Constant voltage output – Selectable from 13.0 to 14.8V DC
Output current up to 100 amps for 3 minutes
70 amps continuous output current
Flash reprogram function
Mode button to select between service and boost modes:
Service mode – prevents battery discharge during service and in the showroom.
Boost mode – for quickly adding energy to a severely discharged or large capacity battery
